One-hand operation, easy to use. Equipped with high-pressure protection.
Air-cooled, 1-piston dry compressor Only 13.5 kg, easy to transport.
Refrigerants :
Category III (R12, R134A, R401C, R406A, R500)
Category IV (R22, R401A, R401B, R402B, R407C, R407D, R408A, R409A, R411A, R411B,
R412A, R502, R509)
Category V (R402A, R404A, R407A, R407B, R410A, R507) including R32 and 1234yf
Power supply 230 V/ 50-60 Hz, 115V/60 Hz, 100 V/50-60 Hz 3/4 HP motor
Speed 1450 rpm 50 Hz, 1750 rpm 60 Hz
Automatic safety cut-out 38.5 bar / 3850 kPa (558 psi)
Recovery rate in kg/min :
Category III: Steam 0.23, Liquid 1.57, Push/pull 4.64
Category IV: Steam 0.25, Liquid 1.80, Push/pull 5.57
Category V: Steam 0.26, Liquid 2.20, Push/pull 6.22
Operating temperature from 0 to 40°C.
Dimensions: 400 x 250 x 355 mm
