692 FE ELECTRONIC TIMER – 0 TO 99 MINUTES – 230 V

Pulse timeout: Controls by front panel keys- Timer range from 0 to 99 minutes in 1 minute increments 2-digit display- Timer remains in memory (ideal for repetitive work)- Audible signal of 1 min at the end of the time delay (30 sec intermittent sound + 30 sec continuous sound)- Output 1 changeover relay 5 A/250 V- 15 minutes backup in case of power failure- Waterproof front panel housing 72 x 72 mm – Depth 43 mm- Flush mounting in cut-out 67 x 67 mm- Mounting by means of cbulbing bracket- Connection by plug-in connector- Power supply 230 V – 50 Hz
