Equipped with a liquid crystal display with pixel matrix for text display, 16.5 mm top and 9 mm bottom display.
Four touch-sensitive keys. Used in harsh environments, IP65 protection rating.
Hot or cold operation.
1 analog input, 2 digital inputs (digital input 1 as alternative to logic output), 2 relays (make), 1 logic output 0/14 V (as alternative to digital input 1) incl. timer, ramp and program function.
Multi-sensor input: TCJ/TCK/TCL/TCS/PT100/PT1000/TENSION/COURANT.
Temperature ranges (TCJ -210/+1200°C) (TCK -270/+1300°C) (TCS -50/+1768°C) (PT100 -200/+850°C) (VOLTAGE 0/10 V) (CURRENT 4/20 mA).
Dimensions 96 x 48 x 65 mm.
POWER SUPPLY 110 to 240 V.
****Replaces ITRON08Q****
