• 1 x 16 A relay output for compressor
• 1 x 8 A relay output for defroster
• 1 x 8 A relay output for evaporator propeller
• 1 configurable digital input (own contact)
• 2 NTC/PTC probes to be selected (not included)
• Frontal size 78 x 37 mm depth 60 mm
• Cutout 71 x 29 mm
• Hot Key/TTL serial ouput
• 12 V ac/dc power supply
XR60CX 12V DIGITAL CONTROLLER
For medium and low temperature ventilated applications with double humidity function on demand.
| SKU: | XR60CX-0N0C3 | Brands: | DIXELL |
| Weight | 0.5 kg |
You must log in to view prices.
Additional information
| Weight | 0,5 kg |
|---|
