XT110D 230V DIGITAL CONTROLLER

• 3 digit display, decimal point
• Probe inputs: NTC, PTC, Pt100, TcJ, TcK, TcS, 4-20 mA, 0-1V, 0-10V
• 1st stage no 8A/nc 5A relay outputs
• Hot key/Prog tool output: present
• Serial ouput TTL
• Analog output optional 4-20 mA
• Digital input: present
• Buzzer: optional
• Precision: Better than 1% at full scale
• Case: Self-extinguishing ABS
• Type of display: Red LED (height 13 mm)
• Storage: EEPROM memory
• Operating temperature range 0°/60°C
• Storage temperature range -30°/85°C
• Relative humidity: 20-85%
• Resolution: 0.1°C.
• Connections: Screw-on terminal block for wires <2.5mm² • 230Vac power supply
